Control Centre Switzerland
The operation of the pipelines is overseen from the Control Centre at the Nord Stream headquarters in Zug. Operators are in constant contact with the supplier of the gas as well as the receivers to assess the flow of gas on a daily basis. The control system is linked via a dedicated cable and satellite connection to the sensors and valve controls at both landfalls, enabling the operators to monitor all parameters of gas flow. The Control Centre is equipped with a large video wall display, as well as operator and engineering work stations.
